Max working ability

Flat Iron

≤10×60mm

Square Steel

≤20×20mm

Other work piece diameter

≤￠30mm

Electric motor

performance

Voltage :380-50HZ

Output surge electric current :300A-1400A

The range of input Voltage :320V-420V

Input electric current :4-36A

Main features

1）Quickly heating: It take 10second to heat the 20cm² section.

2）Electricity consumption: It saves 60% than other electronic tube-type  equipment

3）The indecorum can be disassembly and assembly, so it is suit to many kinds work pieces.

4） Auto- refrigeration system

External dimension

1050mm×680mm×1520mm

N. WEIGHT (kg)

230

G. WEIGHT (kg)

260
